Preview image
A 3D product preview with editable artwork placement. The downloads contain artwork areas; manufacturing patterns and hardware drawings are not included. The artwork is a sample from a fictional brand — swap in your own in the editor.
Artwork placementApparel & merchandise
Junior asymmetric-zip biker jacket decoration template
A cropped-waist jacket with a zipper running diagonally from the collar to an off-centre line down to the hem, broad turned lapels either side of its open neck, welt pockets and ribbed cuffs. The front artwork sits on the wearer’s right below the lapel. Optional left/right upper-arm artwork edits independently on both front and rear sleeve faces. Exported pieces are artwork presentation references; confirm production limits with the garment supplier. Sewing and grading patterns are separate. A ready-sized preset of the asymmetric-zip biker jacket — adjust the object dimensions and decoration area to preview your artwork at size.
Object size440.8 × 552 mm
Artwork area220.4 × 231.8 mm
Download the artwork templatePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, with the artwork area and bleed, without a watermark. See plans
- Reference
- —
- Object size
- Object width 440.8 · Object height 552 mm
- Size range
- Object width 319–928 · Object height 379.5–1104 mm
- Parts
- 2 parts — Front decoration, Back decoration
- Artwork area
- 0.059 m²
- Good for
The flat artwork area
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed.
- Artwork boundary
- Bleed 3 mm
Adjustable in the editor
Alongside dimensions, the template offers 3 options; the template and 3D preview follow each change.
- Separate sleeve artworkon / off
- Rear sleeve artworkon / off
- Object colour17 options
The asymmetric-zip biker jacket family
The same model with sizes and artwork options ready to customize.
Preset
Preset
Similar structures
Other structures built in a similar way, matched on code family, category, closures and proportions.
Make this junior asymmetric-zip biker jacket yours
Set the artwork area, add your design and export the dimensioned artwork template, or stage the product in a 3D scene.
