Preview image
The real blank at this size, folded by the same engine as the studio. The artwork is a sample from a fictional brand — swap in your own in the editor.
DM-BLURAY-CASE-01Cards & tags
4K UHD black case dieline
A translucent blue keep case with a continuous front, spine and back inlay at the 148 mm Blu-ray height, an optional interior insert and a printed disc. Print pieces only; confirm the inlay and spine with your replicator. A ready-sized preset of the blu-ray case + disc — change the length, width and height and every panel, tuck and glue flap is redrawn to match.
Inside128.5 × 12 × 148 mm
Outside128.5 × 12 × 148 mm
Flat blank269 × 148 mm
Download the dielinePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, cut, crease and bleed on separate layers, without a watermark. See plans
- Reference
- DM-BLURAY-CASE-01
- Inside size
- Inlay face width 128.5 · Inlay spine width 12 · Inlay height 148 mm
- Size range
- Inlay face width 120–135 · Inlay spine width 7–15 · Inlay height 140–155 mm
- Manufacturing
- 128.5 × 12 × 148 mm score to score · inside vs outside sizes
- Parts
- 2 parts — DVD cover inlay, Disc face · printable annulus
- Board area
- 0.051 m² · about 12 up on a 720 × 1020 mm sheet
- Default board
- Art paper 170 g · 0.16 mm caliper
- Board options
- Paper 170SBS 300SBS 18 pt
- Good for
The flat dieline
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed. How to read a dieline.
- Crease
- Cut
- Bleed 3 mm
How the blank is sized
Score-to-score panel sizes of this DM-BLURAY-CASE-01 blank at the default size, with the formula each one follows. L, W and H are the inside dimensions; T is the board caliper (0.16 mm for Art paper 170 g). Change the size or board in the editor and every panel is recalculated.
| Panel | Size (mm) | Formula |
|---|---|---|
| Back coverDVD cover inlay | 128.5 × 148 | L × H |
| SpineDVD cover inlay | 12 × 148 | W × H |
| Front coverDVD cover inlay | 128.5 × 148 | L × H |
| Disc face · printable annulusDisc face · printable annulus | 118 × 118 | – |
Adjustable in the editor
Beyond the size and board, this structure exposes 4 options; the template and 3D preview follow each change.
- Case opening°
- Unprinted hub diametermm
- Interior inserton / off
- Case colour3 options
The blu-ray case + disc family
The same structure with sizes, boards and options set for a use.
Preset
Preset
Preset
Similar structures
Other structures built in a similar way, matched on code family, category, closures and proportions.
Make this 4k uhd black case yours
Open it in the editor to set your size, drop artwork on each face, check bleed and safe areas, and export print-ready PDF with the dieline on its own layer — or stage it in a 3D scene for a mockup.
