A 3D product preview with editable artwork placement. The downloads contain artwork areas; manufacturing patterns and hardware drawings are not included. The artwork is a sample from a fictional brand — swap in your own in the editor.
Artwork placementApparel & merchandise
Chisel-tip highlighter decoration template
A flattened highlighter with a broad sloping felt nib and separate hollow cap. Edit both barrel faces. The export supplies artwork references for the finished marker, with printer-confirmed margins. A parametric template — adjust the object dimensions and decoration area to preview your artwork at size.
Object size22 × 13 × 120 mm
Artwork area17.2 × 43.2 mm
Download the artwork templatePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, with the artwork area and bleed, without a watermark. See plans
- Reference
- —
- Object size
- Barrel width 22 · Barrel depth 13 · Capped length 120 mm
- Size range
- Barrel width 14–30 · Barrel depth 8–20 · Capped length 95–160 mm
- Parts
- 2 parts — Front barrel print reference, Reverse barrel print reference
- Artwork area
- 0.001 m²
- Good for
The flat artwork area
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed.
- Artwork boundary
- Bleed 3 mm
Adjustable in the editor
Alongside dimensions, the template offers 3 options; the template and 3D preview follow each change.
- Object colour4 options
- Cap / ink colour4 options
- Remove capon / off
Ready-sized chisel-tip highlighter presets
The same model with sizes and artwork options ready to customize.
- Preset
Preset
Preset
Similar structures
Other structures built in a similar way, matched on code family, category, closures and proportions.
Make this chisel-tip highlighter yours
Set the artwork area, add your design and export the dimensioned artwork template, or stage the product in a 3D scene.
