US Letter corner spiral notebook dieline
A diagonal three-punch corner coil lets the cover flip back from the writing sheets. Export the sheet and cover trim/punch templates. Glue, wire forming and bindery tolerances are supplier specifications. A ready-sized preset of the corner spiral notebook — change its size and the cut outline, bleed and safe area are redrawn to match.
Inside215.9 × 279.4 mm
Outside215.9 × 279.4 mm
Flat blank215.9 × 279.4 mm
Download the dielinePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, cut, crease and bleed on separate layers, without a watermark. See plans
- Reference
- —
- Inside size
- Sheet width 215.9 · Sheet height 279.4 mm
- Size range
- Sheet width 70–320 · Sheet height 90–420 mm
- Manufacturing
- 215.9 × 279.4 mm score to score · inside vs outside sizes
- Parts
- 3 parts — Front cover, Writing sheet trim / punch reference, Card backing
- Board area
- 0.181 m² · about 9 up on a 720 × 1020 mm sheet
- Default board
- SBS white board 300 g · 0.42 mm caliper
- Board options
- SBS 300SBS 350Kraft 350Paper 170SBS 18 pt
- Good for
The flat dieline
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed. How to read a dieline.
- Cut
- Bleed 3 mm
Adjustable in the editor
Beyond the size and board, this structure exposes 3 options; the template and 3D preview follow each change.
- Sheetscount
- Front coveron / off
- Cover opening°
The corner spiral notebook family
The same structure with sizes, boards and options set for a use.
Preset
Preset
Preset
