A 3D product preview with editable artwork placement. The downloads contain artwork areas; manufacturing patterns and hardware drawings are not included. The artwork is a sample from a fictional brand — swap in your own in the editor.
Artwork placementApparel & merchandise
Fitted cycling bib shorts decoration template
Original fitted mid-thigh shorts with continuous shoulder loops, an open front chest, higher rear bridge, two open sides and leg hems, separate elastic gripper bands and an inner chamois reference. Rear sponsor and four leg faces edit independently. Confirm placement with the supplier; sewing, grading, all-over panels, worn rigs and performance specifications are separate. A parametric template — adjust the object dimensions and decoration area to preview your artwork at size.
Object size360 × 900 mm
Artwork area90 × 144 mm
Download the artwork templatePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, with the artwork area and bleed, without a watermark. See plans
- Reference
- —
- Object size
- Hip width 360 · Garment height 900 mm
- Size range
- Hip width 270–490 · Garment height 675–1125 mm
- Parts
- 5 parts — Lower rear bib decoration, Left leg decoration · front, Right leg decoration · front, Left leg decoration · rear, Right leg decoration · rear
- Artwork area
- 0.064 m²
- Good for
The flat artwork area
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed.
- Artwork boundary
- Bleed 3 mm
Adjustable in the editor
Alongside dimensions, the template offers 2 options; the template and 3D preview follow each change.
- Object colour17 options
- Leg gripper colour3 options
Ready-sized fitted cycling bib shorts presets
The same model with sizes and artwork options ready to customize.
- Preset
Similar structures
Other structures built in a similar way, matched on code family, category, closures and proportions.
Make this fitted cycling bib shorts yours
Set the artwork area, add your design and export the dimensioned artwork template, or stage the product in a 3D scene.
