DM-DUALCUP-01Labels
Dual-compartment drink cup dieline
A clear plastic cup split into two chambers under one rim, with a two-hole lid and two straws. Choose each drink and level; print the cup wrap. A parametric template — change its size and the cut outline, bleed and safe area are redrawn to match.
InsideØ 95 × 150 mm
OutsideØ 95 × 150 mm
Flat blank283.5 × 90 mm
Download the dielinePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, cut, crease and bleed on separate layers, without a watermark. See plans
- Reference
- DM-DUALCUP-01
- Inside size
- Rim diameter 95 · Cup height 150 mm
- Size range
- Rim diameter 70–130 · Cup height 80–220 mm
- Manufacturing
- Ø 95 × 150 mm score to score · inside vs outside sizes
- Parts
- One blank
- Board area
- 0.026 m² · about 21 up on a 720 × 1020 mm sheet
- Default board
- Art paper 170 g · 0.16 mm caliper
- Board options
- Paper 170
- Good for
The flat dieline
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed. How to read a dieline.
- Cut
- Bleed 3 mm
Adjustable in the editor
Beyond the size and board, this structure exposes 5 options; the template and 3D preview follow each change.
- Left drink6 options
- Right drink6 options
- Fill level%
- Lid2 options
- Strawson / off
Ready-sized dual-compartment drink cup presets
The same structure with sizes, boards and options set for a use.
- Preset
Preset
Similar structures
Other structures built in a similar way, matched on code family, category, closures and proportions.
Make this dual-compartment drink cup yours
Open it in the editor to set your size, drop artwork on each face, check bleed and safe areas, and export print-ready PDF with the dieline on its own layer — or stage it in a 3D scene for a mockup.
