The real blank at this size, folded by the same engine as the studio. The artwork is a sample from a fictional brand — swap in your own in the editor.
DM-GRIPCUP-01Labels
Straight mug with rubber band dieline
A handleless reusable cup or tumbler with a raised silicone grip band and a sip lid or clear cap. Print the wall wrap and the band. A ready-sized preset of the reusable cup with grip band — change its size and the cut outline, bleed and safe area are redrawn to match.
InsideØ 82 × 95 mm
OutsideØ 82 × 95 mm
Flat blank257.6 × 85 mm
Download the dielinePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, cut, crease and bleed on separate layers, without a watermark. See plans
- Reference
- DM-GRIPCUP-01
- Inside size
- Rim diameter 82 · Cup height 95 mm
- Size range
- Rim diameter 50–120 · Cup height 60–260 mm
- Manufacturing
- Ø 82 × 95 mm score to score · inside vs outside sizes
- Parts
- One blank
- Board area
- 0.022 m² · about 22 up on a 720 × 1020 mm sheet
- Default board
- Art paper 170 g · 0.16 mm caliper
- Board options
- Paper 170
- Good for
The flat dieline
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed. How to read a dieline.
- Cut
- Bleed 3 mm
Adjustable in the editor
Beyond the size and board, this structure exposes 9 options; the template and 3D preview follow each change.
- Base diameter%
- Band height%
- Band centre%
- Lid3 options
- Body2 options
- Neck ringon / off
- Print the bandon / off
- Body colour5 options
- Band colour5 options
The reusable cup with grip band family
The same structure with sizes, boards and options set for a use.
Preset
Preset
Preset
Similar structures
Other structures built in a similar way, matched on code family, category, closures and proportions.
Make this straight mug with rubber band yours
Open it in the editor to set your size, drop artwork on each face, check bleed and safe areas, and export print-ready PDF with the dieline on its own layer — or stage it in a 3D scene for a mockup.
