The real blank at this size, folded by the same engine as the studio. The artwork is a sample from a fictional brand — swap in your own in the editor.
DM-PDRUM-01Labels
100 L open-top barrel dieline
A blow-moulded plastic barrel with rounded shoulders and rolling ribs, tight-head with bungs or open-head with a clamp-ring lid. Print a label panel or the full wrap, in gloss or matte. A ready-sized preset of the plastic drum (hdpe barrel) — change its size and the cut outline, bleed and safe area are redrawn to match.
InsideØ 450 × 720 mm
OutsideØ 450 × 720 mm
Flat blank405 × 233.6 mm
Download the dielinePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, cut, crease and bleed on separate layers, without a watermark. See plans
