Short-sleeve raglan T-shirt with full-part artwork decoration template
A crew-neck tee with preserved short sleeves, diagonal raglan seams and separately coloured sleeve panels. Optional left/right upper-arm artwork edits independently on both front and rear sleeve faces. An optional full-part mode covers the actual body, complete sleeves and collar/hood/pocket surfaces using original artwork charts. Exported pieces are artwork presentation references; confirm production limits with the garment supplier. Sewing and grading patterns are separate. A ready-sized preset of the short-sleeve raglan t-shirt — adjust the object dimensions and decoration area to preview your artwork at size.
Object size520 × 720 mm
Artwork area651.4 × 720 mm
Download the artwork templatePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, with the artwork area and bleed, without a watermark. See plans
- Reference
- —
- Object size
- Object width 520 · Object height 720 mm
- Size range
- Object width 286–832 · Object height 396–1152 mm
- Parts
- 4 parts — Front body · full-part presentation, Rear body · full-part presentation, Left sleeve · full-part presentation, Right sleeve · full-part presentation
- Artwork area
- 1.385 m²
- Good for
The flat artwork area
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed.
- Artwork boundary
- Bleed 3 mm
Adjustable in the editor
Alongside dimensions, the template offers 2 options; the template and 3D preview follow each change.
- Object colour17 options
- Full-part artwork presentationon / off
