A 3D product preview with editable artwork placement. The downloads contain artwork areas; manufacturing patterns and hardware drawings are not included. The artwork is a sample from a fictional brand — swap in your own in the editor.
Artwork placementDisplay
Indoor teardrop flag with plate base graphic template
A taut curved flag on a matching bent pole and a freestanding base, with independently editable front and reverse artwork. Export the visible fabric face; hems, pole sleeves and sewing allowances must follow your flag supplier’s template. A ready-sized preset of the teardrop flag — adjust the object dimensions and decoration area to preview your artwork at size.
Object size500 × 1600 mm
Artwork area500 × 1594 mm
Download the artwork templatePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, with the artwork area and bleed, without a watermark. See plans
- Reference
- —
- Object size
- Fabric width 500 · Fabric height 1600 mm
- Size range
- Fabric width 350–1400 · Fabric height 900–4200 mm
- Parts
- 2 parts — Front flag artwork, Reverse flag artwork
- Artwork area
- 1.103 m²
- Good for
The flat artwork area
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed.
- Artwork boundary
- Bleed 3 mm
Adjustable in the editor
Alongside dimensions, the template offers 1 option; the template and 3D preview follow each change.
- Display base2 options
The teardrop flag family
The same model with sizes and artwork options ready to customize.
Preset
Preset
Preset
Similar structures
Other structures built in a similar way, matched on code family, category, closures and proportions.
Make this indoor teardrop flag with plate base yours
Set the artwork area, add your design and export the dimensioned artwork template, or stage the product in a 3D scene.
