Preview image
A 3D product preview with editable artwork placement. The downloads contain artwork areas; manufacturing patterns and hardware drawings are not included. The artwork is a sample from a fictional brand — swap in your own in the editor.
DM-VIDEOWALL-01Apparel & merchandise
Corner LED video wall decoration template
A grid of LED cabinets or narrow-bezel LCD panels showing one tiled artwork or one per tile, on a wall, a floor stand or round a corner. A ready-sized preset of the multi-panel led / lcd video wall — adjust the object dimensions and decoration area to preview your artwork at size.
Object size500 × 500 mm
Artwork area4000 × 2000 mm
Download the artwork templatePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, with the artwork area and bleed, without a watermark. See plans
- Reference
- DM-VIDEOWALL-01
- Object size
- Tile width 500 · Tile height 500 mm
- Size range
- Tile width 250–1500 · Tile height 250–1000 mm
- Parts
- One artwork area
- Artwork area
- 8.000 m²
- Good for
The flat artwork area
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed.
- Artwork boundary
- Bleed 3 mm
Adjustable in the editor
Alongside dimensions, the template offers 8 options; the template and 3D preview follow each change.
- Columnscount
- Rowscount
- Bezel gapmm
- Mounting3 options
- Corner after columncount
- Corner2 options
- Artwork2 options
- Bezel / frame3 options
The multi-panel led / lcd video wall family
The same model with sizes and artwork options ready to customize.
Preset
Preset
Preset
Preset
Similar structures
Other structures built in a similar way, matched on code family, category, closures and proportions.
Make this corner led video wall yours
Set the artwork area, add your design and export the dimensioned artwork template, or stage the product in a 3D scene.
