A 3D product preview with editable artwork placement. The downloads contain artwork areas; manufacturing patterns and hardware drawings are not included. The artwork is a sample from a fictional brand — swap in your own in the editor.
DM-WIREGRID-01Apparel & merchandise
Small counter grid with round header decoration template
A welded wire grid panel in a freestanding frame with a cut-profile graphic board fixed to the mesh and optional peg hooks. A ready-sized preset of the wire-grid floor display — adjust the object dimensions and decoration area to preview your artwork at size.
Object size400 × 700 mm
Artwork area360 × 315 mm
Download the artwork templatePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, with the artwork area and bleed, without a watermark. See plans
- Reference
- DM-WIREGRID-01
- Object size
- Frame width 400 · Frame height 700 mm
- Size range
- Frame width 300–1500 · Frame height 600–2400 mm
- Parts
- One artwork area
- Artwork area
- 0.089 m²
- Good for
The flat artwork area
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed.
- Artwork boundary
- Bleed 3 mm
Adjustable in the editor
Alongside dimensions, the template offers 8 options; the template and 3D preview follow each change.
- Grid pitchmm
- Foot2 options
- Graphic3 options
- Graphic shape4 options
- Header height%
- Graphic on both faceson / off
- Peg hookscount
- Wire3 options
The wire-grid floor display family
The same model with sizes and artwork options ready to customize.
Preset
Preset
Preset
Similar structures
Other structures built in a similar way, matched on code family, category, closures and proportions.
Make this small counter grid with round header yours
Set the artwork area, add your design and export the dimensioned artwork template, or stage the product in a 3D scene.
