Preview image
The real blank at this size, folded by the same engine as the studio. The artwork is a sample from a fictional brand — swap in your own in the editor.
ECMA F60.91.00.00Cards & tags
Open card wallet dieline
Pocket for a gift card and its carrier, open on one side. A ready-sized preset of the board wallet — change the length, width and height and every panel, tuck and glue flap is redrawn to match.
Inside120 × 95 mm
Outside120.5 × 96 mm
Flat blank240.5 × 129.9 mm
Download the dielinePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, cut, crease and bleed on separate layers, without a watermark. See plans
- Reference
- ECMA F60.91.00.00
- Inside size
- Width 120 · Height 95 mm
- Size range
- Width 50–350 · Height 40–350 mm
- Manufacturing
- 120.3 × 95.5 mm score to score · inside vs outside sizes
- Parts
- One blank
- Board area
- 0.027 m² · about 14 up on a 720 × 1020 mm sheet
- Default board
- SBS white board 350 g · 0.5 mm caliper
- Board options
- SBS 350SBS 300FBB 400GD2 350Kraft 350Black 350SBS 18 pt
- Good for
The flat dieline
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed. How to read a dieline.
- Crease
- Cut
- Glue area
- Bleed 3 mm
How the blank is sized
Score-to-score panel sizes of this ECMA F60.91.00.00 blank at the default size, with the formula each one follows. L, W and H are the inside dimensions; T is the board caliper (0.5 mm for SBS white board 350 g). Change the size or board in the editor and every panel is recalculated.
| Panel | Size (mm) | Formula |
|---|---|---|
| Cover | 120.3 × 95.5 | L + T/2 × H + T |
| Back | 120.3 × 95.5 | L + T/2 × H + T |
| Top glue flap | 116.8 × 17.2 | – |
| Bottom glue flap | 116.8 × 17.2 | – |
Adjustable in the editor
Beyond the size and board, this structure exposes 2 options; the template and 3D preview follow each change.
- Closure3 options
- End flap depthmm
The board wallet family
The same structure with sizes, boards and options set for a use.
Preset
Preset
Similar structures
Other structures built in a similar way, matched on code family, category, closures and proportions.
Make this open card wallet yours
Open it in the editor to set your size, drop artwork on each face, check bleed and safe areas, and export print-ready PDF with the dieline on its own layer — or stage it in a 3D scene for a mockup.
