A 3D product preview with editable artwork placement. The downloads contain artwork areas; manufacturing patterns and hardware drawings are not included. The artwork is a sample from a fictional brand — swap in your own in the editor.
Artwork placementLabels
Oval deodorant stick label template
Oval twist-up dispenser with a raised solid product, base dial and removable overcap. Front and back labels follow the oval wall; the plastic mould and fill weight require the supplier’s specifications. A parametric template — adjust the object dimensions and decoration area to preview your artwork at size.
Object size56 × 32 × 116 mm
Artwork area47 × 55.4 mm
Download the artwork templatePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, with the artwork area and bleed, without a watermark. See plans
- Reference
- —
- Object size
- Body width 56 · Body depth 32 · Open height 116 mm
- Size range
- Body width 38–85 · Body depth 22–55 · Open height 70–160 mm
- Parts
- 2 parts — Front artwork, Back artwork
- Artwork area
- 0.005 m²
- Good for
The flat artwork area
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed.
- Artwork boundary
- Bleed 3 mm
Adjustable in the editor
Alongside dimensions, the template offers 7 options; the template and 3D preview follow each change.
- Label width (0 = auto)mm
- Label height (0 = auto)mm
- Back labelon / off
- Body colour10 options
- Cap colour10 options
- Show cap on producton / off
- Solid colour10 options
Ready-sized oval deodorant stick presets
The same model with sizes and artwork options ready to customize.
- Preset
Preset
Preset
Preset
Preset
Preset
Preset
Preset
Similar structures
Other structures built in a similar way, matched on code family, category, closures and proportions.
Make this oval deodorant stick yours
Set the artwork area, add your design and export the dimensioned artwork template, or stage the product in a 3D scene.
