The real blank at this size, folded by the same engine as the studio. The artwork is a sample from a fictional brand — swap in your own in the editor.
DM-OILCAN-01Labels
Metal oil can (pour neck) dieline
A seamed metal oil can, rectangular or round, with a small capped pour neck and an optional folding grip, wire bail or handle loop. Plain or ribbed walls; print the front and back panels or the round wrap. A parametric template — change its size and the cut outline, bleed and safe area are redrawn to match.
Inside160 × 95 × 240 mm
Outside160 × 95 × 240 mm
Flat blank152 × 224 mm
Download the dielinePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, cut, crease and bleed on separate layers, without a watermark. See plans
- Reference
- DM-OILCAN-01
- Inside size
- Width / diameter 160 · Depth 95 · Body height 240 mm
- Size range
- Width / diameter 50–350 · Depth 30–250 · Body height 80–450 mm
- Manufacturing
- 160 × 95 × 240 mm score to score · inside vs outside sizes
- Parts
- 2 parts — Front panel, Back panel
- Board area
- 0.068 m² · about 18 up on a 720 × 1020 mm sheet
- Default board
- Art paper 170 g · 0.16 mm caliper
- Board options
- Paper 170
- Good for
