Preview image
The real blank at this size, folded by the same engine as the studio. The artwork is a sample from a fictional brand — swap in your own in the editor.
Parametric structureDisplay
Wide counter easel display — Easel-back display card dieline
Editable 300 × 90 × 180 mm starting point using easel-back display card. Adjust the dimensions to your product before prototyping. A ready-sized preset of the easel-back display card — change the length, width and height and every panel, tuck and glue flap is redrawn to match.
Inside300 × 90 × 180 mm
Outside300 × 90 × 180 mm
Flat blank300 × 488.7 mm
Download the dielinePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, cut, crease and bleed on separate layers, without a watermark. See plans
- Reference
- —
- Inside size
- Face width 300 · Stand depth 90 · Face height 180 mm
- Size range
- Face width 60–500 · Stand depth 20–200 · Face height 60–600 mm
- Manufacturing
- 300 × 90 × 180 mm score to score · inside vs outside sizes
- Parts
- One blank
- Board area
- 0.091 m² · about 4 up on a 720 × 1020 mm sheet
- Default board
- Folding boxboard 400 g · 0.6 mm caliper
- Board options
- FBB 400SBS 350Kraft 350E-flute WSBS 18 pt
- Good for
The flat dieline
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed. How to read a dieline.
- Crease
- Cut
- Glue area
- Bleed 3 mm
How the blank is sized
Score-to-score panel sizes at the default size, with the formula each one follows. L, W and H are the inside dimensions; T is the board caliper (0.6 mm for Folding boxboard 400 g). Change the size or board in the editor and every panel is recalculated.
| Panel | Size (mm) | Formula |
|---|---|---|
| Display face | 300 × 180 | L × H |
| Rear strut | 120 × 201.2 | – |
| Stand base | 120 × 89.4 | – × W − T |
| Glue foot | 120 × 18 | – |
Adjustable in the editor
Beyond the size and board, this structure exposes 2 options; the template and 3D preview follow each change.
- Support widthmm
- Glue footmm
The easel-back display card family
The same structure with sizes, boards and options set for a use.
Preset
Preset
Preset
Preset
Preset
Preset
Preset
Preset
Preset
Similar structures
Other structures built in a similar way, matched on code family, category, closures and proportions.
Make this wide counter easel display — easel-back display card yours
Open it in the editor to set your size, drop artwork on each face, check bleed and safe areas, and export print-ready PDF with the dieline on its own layer — or stage it in a 3D scene for a mockup.
