Formal lace-up shoe decoration template
An original formal lace-up: an elongated almond toe, low leather upper with a hollow foot opening, separate tongue, five-pair lacing with closely set eyelets, a thin leather-look sole and a separate stacked heel. Export supplier artwork placement references. These presentation dimensions are not shoe sizing, footwear lasts, production moulds, protective safety engineering, certifications or garment cutting patterns. A parametric template — adjust the object dimensions and decoration area to preview your artwork at size.
Object size295 × 98 × 95 mm
Artwork area123.9 × 20.9 mm
Download the artwork templatePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, with the artwork area and bleed, without a watermark. See plans
- Reference
- —
- Object size
- Shoe length 295 · Shoe width 98 · Shoe height 95 mm
- Size range
- Shoe length 221.3–368.8 · Shoe width 78.4–117.6 · Shoe height 76–114 mm
- Parts
- 3 parts — Exterior side decoration, Interior side decoration, Tongue decoration above laces
- Artwork area
- 0.006 m²
- Good for
The flat artwork area
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed.
- Artwork boundary
- Bleed 3 mm
Adjustable in the editor
Alongside dimensions, the template offers 5 options; the template and 3D preview follow each change.
- Upper leather6 options
- Rubber sole6 options
- Tongue leather6 options
- Laces6 options
- Inner lining6 options
Ready-sized formal lace-up shoe presets
The same model with sizes and artwork options ready to customize.
- Preset
Preset
