Preview image
The real blank at this size, folded by the same engine as the studio. The artwork is a sample from a fictional brand — swap in your own in the editor.
Parametric structureBags & pouches
Small plastic drawstring bag dieline
160 × 45 × 220 mm starting dimensions. Adjust to your actual container or product. A ready-sized preset of the plastic drawstring bag — change the length, width and height and every panel, tuck and glue flap is redrawn to match.
Inside160 × 45 × 220 mm
Outside160 × 45 × 220 mm
Flat blank160 × 220 mm
Download the dielinePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, cut, crease and bleed on separate layers, without a watermark. See plans
- Reference
- —
- Inside size
- Flat web width 160 · Filled depth 45 · Web height 220 mm
- Size range
- Flat web width 120–500 · Filled depth 30–180 · Web height 160–600 mm
- Manufacturing
- 160 × 45 × 220 mm score to score · inside vs outside sizes
- Parts
- 2 parts — Front film web, Back film web
- Board area
- 0.070 m² · about 16 up on a 720 × 1020 mm sheet
- Default board
- White PET / PE laminate · 0.09 mm caliper
- Board options
- White PET/PEClear PET/PE
- Good for
The flat dieline
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed. How to read a dieline.
- Cut
- Bleed 3 mm
How the blank is sized
Score-to-score panel sizes at the default size, with the formula each one follows. L, W and H are the inside dimensions; T is the board caliper (0.09 mm for White PET / PE laminate). Change the size or board in the editor and every panel is recalculated.
| Panel | Size (mm) | Formula |
|---|---|---|
| front film webFront film web | 160 × 180 | L × – |
| Drawstring channel foldFront film web | 160 × 40 | L × – |
| back film webBack film web | 160 × 180 | L × – |
| Drawstring channel foldBack film web | 160 × 40 | L × – |
Adjustable in the editor
Beyond the size and board, this structure exposes 2 options; the template and 3D preview follow each change.
- Side and base sealsmm
- Folded cord channelmm
The plastic drawstring bag family
The same structure with sizes, boards and options set for a use.
Preset
Preset
Preset
Preset
Preset
Preset
Preset
Preset
Similar structures
Other structures built in a similar way, matched on code family, category, closures and proportions.
Make this small plastic drawstring bag yours
Open it in the editor to set your size, drop artwork on each face, check bleed and safe areas, and export print-ready PDF with the dieline on its own layer — or stage it in a 3D scene for a mockup.
