Small drawstring gift bag dieline
Two film webs with sealed sides and bottom, a folded top drawstring channel, gathered mouth and two cord handles. Exports show the web rectangles and channel fold; cord hardware and conversion allowances need a supplier trial. A ready-sized preset of the plastic drawstring bag — change the length, width and height and every panel, tuck and glue flap is redrawn to match.
Inside180 × 45 × 240 mm
Outside180 × 45 × 240 mm
Flat blank180 × 240 mm
Download the dielinePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, cut, crease and bleed on separate layers, without a watermark. See plans
- Reference
- —
- Inside size
- Flat web width 180 · Filled depth 45 · Web height 240 mm
- Size range
- Flat web width 120–500 · Filled depth 30–180 · Web height 160–600 mm
- Manufacturing
- 180 × 45 × 240 mm score to score · inside vs outside sizes
- Parts
- 2 parts — Front film web, Back film web
- Board area
- 0.086 m² · about 12 up on a 720 × 1020 mm sheet
- Default board
- White PET / PE laminate · 0.09 mm caliper
- Board options
- White PET/PEClear PET/PE
- Good for
The flat dieline
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed. How to read a dieline.
- Cut
- Bleed 3 mm
How the blank is sized
Score-to-score panel sizes at the default size, with the formula each one follows. L, W and H are the inside dimensions; T is the board caliper (0.09 mm for White PET / PE laminate). Change the size or board in the editor and every panel is recalculated.
| Panel | Size (mm) | Formula |
|---|---|---|
| front film webFront film web | 180 × 200 | L × – |
| Drawstring channel foldFront film web | 180 × 40 | L × – |
| back film webBack film web | 180 × 200 | L × – |
| Drawstring channel foldBack film web | 180 × 40 | L × – |
