12 in poly-lined sleeve with cut corners
Preview image

A 3D product preview with editable artwork placement. The downloads contain artwork areas; manufacturing patterns and hardware drawings are not included. The artwork is a sample from a fictional brand — swap in your own in the editor.

DM-RECSLEEVE-01Apparel & merchandise

12 in poly-lined sleeve with cut corners decoration template

A printed paper inner sleeve (square, round-bottom or poly-lined with clipped corners, with or without a centre hole) with the record half out, or a clear outer sleeve with a top or adhesive flap round a printed jacket or bare record. A ready-sized preset of the record inner sleeve and clear outer sleeve — adjust the object dimensions and decoration area to preview your artwork at size.

Object size302 × 8 × 60 mm
Artwork area318 × 318 mm
Customize freeOpen in 3D Studio
Download the artwork templatePro
Artwork boundary preview

Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, with the artwork area and bleed, without a watermark. See plans

Reference
DM-RECSLEEVE-01
Object size
Record diameter 302 · Paper sleeve allowance 8 · Record pulled out 60 mm
Size range
Record diameter 175–302 · Paper sleeve allowance 4–20 · Record pulled out 0–200 mm
Parts
2 parts — Inner sleeve front, Inner sleeve back
Artwork area
0.201 m²
Good for
record sleeveinner sleeverecord inner sleevevinyl inner sleeveround bottom sleevepoly lined sleeveclear record sleevevinyl outer sleeveresealable record sleeverecord protector

The flat artwork area

Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed.

  • Artwork boundary
  • Bleed 3 mm
12 in poly-lined sleeve with cut corners artwork boundary

Adjustable in the editor

Alongside dimensions, the template offers 3 options; the template and 3D preview follow each change.

  • Sleeve2 options
  • Inner sleeve shape3 options
  • Centre holeon / off

The record inner sleeve and clear outer sleeve family

The same model with sizes and artwork options ready to customize.

Similar structures

Other structures built in a similar way, matched on code family, category, closures and proportions.

All apparel & merchandise templates

Make this 12 in poly-lined sleeve with cut corners yours

Set the artwork area, add your design and export the dimensioned artwork template, or stage the product in a 3D scene.

Customize freeSee it as a mockup
