Preview image
The real blank at this size, folded by the same engine as the studio. The artwork is a sample from a fictional brand — swap in your own in the editor.
Parametric structureCards & tags
Wedding table photo frame dieline
A hollow paper frame with mitred rails and glued return feet. Keep the printed insert on the backing, or set its recess independently using folded support ledges. A ready-sized preset of the paper shadow frame — change the length, width and height and every panel, tuck and glue flap is redrawn to match.
Inside130 × 170 × 14 mm
Outside130 × 170 × 14.8 mm
Flat blank231 × 271 mm
Download the dielinePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, cut, crease and bleed on separate layers, without a watermark. See plans
- Reference
- —
- Inside size
- Frame width 130 · Frame height 170 · Frame depth 14 mm
- Size range
- Frame width 100–420 · Frame height 100–420 · Frame depth 8–45 mm
- Manufacturing
- 130.5 × 170.5 × 14.5 mm score to score · inside vs outside sizes
- Parts
- 2 parts — Photo / art insert, Hollow frame blank
- Board area
- 0.064 m² · about 8 up on a 720 × 1020 mm sheet
- Default board
- SBS white board 350 g · 0.5 mm caliper
- Board options
- SBS 350FBB 400Kraft 350Black 350SBS 18 pt
- Good for
The flat dieline
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed. How to read a dieline.
- Crease
- Cut
- Glue area
- Bleed 3 mm
How the blank is sized
Score-to-score panel sizes at the default size, with the formula each one follows. L, W and H are the inside dimensions; T is the board caliper (0.5 mm for SBS white board 350 g). Change the size or board in the editor and every panel is recalculated.
| Panel | Size (mm) | Formula |
|---|---|---|
| Photo / art insertPhoto / art insert | 104 × 144 | – |
| Frame backingHollow frame blank | 130 × 170 | L × W |
| Outer frame wall ×2Hollow frame blank | 130 × 14.5 | L × H + T |
| Mitred frame face ×2Hollow frame blank | 130 × 12 | L × – |
| Inside frame wall ×2Hollow frame blank | 106 × 14 | – × H |
| Frame glue foot ×2Hollow frame blank | 104 × 10 | – |
| Outer frame wall ×2Hollow frame blank | 14.5 × 170 | H + T × W |
| Mitred frame face ×2Hollow frame blank | 12 × 170 | – × W |
| Inside frame wall ×2Hollow frame blank | 14 × 146 | H × – |
| Frame glue foot ×2Hollow frame blank | 10 × 144 | – |
Adjustable in the editor
Beyond the size and board, this structure exposes 2 options; the template and 3D preview follow each change.
- Frame bordermm
- Picture recessmm
