The real blank at this size, folded by the same engine as the studio. The artwork is a sample from a fictional brand — swap in your own in the editor.
Parametric structureLabels
Tapered pot body sleeve dieline
An unshrunk rectangular PETG film web with a longitudinal seam, layflat guides and clear cut margins. Preview it around a cylinder, taper or shoulder bottle. The preview shows nominal circumferential compression; film shrink curves, artwork pre-distortion, length shrink and the actual container profile require a converter’s distortion proof. This is a sleeve artwork guide, not a container mould. A ready-sized preset of the full-body shrink sleeve — change the length, width and height and every panel, tuck and glue flap is redrawn to match.
InsideØ 90 × 85 mm
OutsideØ 90 × 85 mm
Flat blank294 × 85 mm
Download the dielinePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, cut, crease and bleed on separate layers, without a watermark. See plans
- Reference
- —
- Inside size
- Maximum container diameter 90 · Sleeve cut length 85 mm
- Size range
- Maximum container diameter 30–180 · Sleeve cut length 40–350 mm
- Manufacturing
- Ø 90 × 85 mm score to score · inside vs outside sizes
- Parts
- One blank
- Board area
- 0.025 m² · about 22 up on a 720 × 1020 mm sheet
- Default board
- PETG shrink film 40 µm · 0.04 mm caliper
- Board options
- PETG shrink
- Good for
The flat dieline
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed. How to read a dieline.
- Crease
- Cut
- Glue area
- Bleed 3 mm
How the blank is sized
Score-to-score panel sizes at the default size, with the formula each one follows. L, W and H are the inside dimensions; T is the board caliper (0.04 mm for PETG shrink film 40 µm). Change the size or board in the editor and every panel is recalculated.
