Preview image
A 3D product preview with editable artwork placement. The downloads contain artwork areas; manufacturing patterns and hardware drawings are not included. The artwork is a sample from a fictional brand — swap in your own in the editor.
DM-WAYFIND-01Apparel & merchandise
Double-post framed map stand decoration template
A monolith pylon, framed map stand, fingerpost with directional blades, crossarm hanging sign or stacked directory frame. A ready-sized preset of the wayfinding totem and map stand — adjust the object dimensions and decoration area to preview your artwork at size.
Object size1200 × 2000 mm
Artwork area1200 × 900 mm
Download the artwork templatePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, with the artwork area and bleed, without a watermark. See plans
- Reference
- DM-WAYFIND-01
- Object size
- Sign width 1200 · Overall height 2000 mm
- Size range
- Sign width 200–2000 · Overall height 900–4500 mm
- Parts
- 2 parts — Map / poster panel, Map / poster panel (rear)
- Artwork area
- 2.160 m²
- Good for
The flat artwork area
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed.
- Artwork boundary
- Bleed 3 mm
Adjustable in the editor
Alongside dimensions, the template offers 5 options; the template and 3D preview follow each change.
- Sign5 options
- Panel height%
- Postscount
- Print the back faceson / off
- Frame5 options
The wayfinding totem and map stand family
The same model with sizes and artwork options ready to customize.
Preset
Preset
Preset
Preset
Preset
Preset
Similar structures
Other structures built in a similar way, matched on code family, category, closures and proportions.
Make this double-post framed map stand yours
Set the artwork area, add your design and export the dimensioned artwork template, or stage the product in a 3D scene.
