Preview image
The real blank at this size, folded by the same engine as the studio. The artwork is a sample from a fictional brand — swap in your own in the editor.
FEFCO 0219Shipping
Double lid with safety tabs dieline
Corrugated case with handle closure, with construction-specific folds and closures on a corrugated tube. A ready-sized preset of the corrugated case with handle closure — change the length, width and height and every panel, tuck and glue flap is redrawn to match.
Inside400 × 280 × 240 mm
Outside403.2 × 286.4 × 246.4 mm
Flat blank1384.8 × 721.6 mm
Download the dielinePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, cut, crease and bleed on separate layers, without a watermark. See plans
- Reference
- FEFCO 0219
- Inside size
- Length 400 · Width 280 · Height 240 mm
- Size range
- Length 120–1200 · Width 80–800 · Height 70–1000 mm
- Manufacturing
- 401.6 × 281.6 × 243.2 mm score to score · inside vs outside sizes
- Parts
- One blank
- Board area
- 0.792 m²
- Default board
- E-flute kraft / kraft · 1.6 mm caliper
- Board options
- B-fluteEB doubleE-flute KE-flute WF-flute
- Good for
The flat dieline
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed. How to read a dieline.
- Crease
- Cut
- Glue area
- Bleed 3 mm
How the blank is sized
Score-to-score panel sizes of this FEFCO 0219 blank at the default size, with the formula each one follows. L, W and H are the inside dimensions; T is the board caliper (1.6 mm for E-flute kraft / kraft). Change the size or board in the editor and every panel is recalculated.
| Panel | Size (mm) | Formula |
|---|---|---|
| Front | 401.6 × 243.2 | L + T × H + 2T |
| Left side | 281.6 × 243.2 | W + T × H + 2T |
| Back | 401.6 × 243.2 | L + T × H + 2T |
| Right side | 280 × 243.2 | W × H + 2T |
| Glue flap | 20 × 243.2 | – × H + 2T |
| Snap end | 281.6 × 93.3 | W + T × – |
| Snap end | 280 × 93.3 | W × – |
| Snap bottom | 401.6 × 182 | L + T × – |
| Snap tuck | 401.6 × 180.4 | L + T × – |
| top inner | 398.4 × 278.4 | L − T × W − T |
| top outer | 398.4 × 278.4 | L − T × W − T |
| front lock tab | 60 × 18 | – |
| inner tuck | 398.4 × 18 | L − T × – |
| outer lock tab | 140 × 18 | – |
| top left | 268.8 × 98 | – |
| top right | 267.2 × 98 | – |
Adjustable in the editor
Beyond the size and board, this structure exposes 3 options; the template and 3D preview follow each change.
- Construction3 options
- Handle / header heightmm
- Handhold widthmm
The corrugated case with handle closure family
The same structure with sizes, boards and options set for a use.
Preset
Preset
Similar structures
Other structures built in a similar way, matched on code family, category, closures and proportions.
Make this double lid with safety tabs yours
Open it in the editor to set your size, drop artwork on each face, check bleed and safe areas, and export print-ready PDF with the dieline on its own layer — or stage it in a 3D scene for a mockup.
