Preview image
The real blank at this size, folded by the same engine as the studio. The artwork is a sample from a fictional brand — swap in your own in the editor.
Parametric structureCards & tags
Board envelope dieline
A paperboard wallet envelope with glued side seals and an optional retained slit lock, address window or tear strip. A parametric template — change the length, width and height and every panel, tuck and glue flap is redrawn to match.
Inside229 × 162 mm
Outside229 × 162 mm
Flat blank253 × 368.1 mm
Download the dielinePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, cut, crease and bleed on separate layers, without a watermark. See plans
- Reference
- —
- Inside size
- Width 229 · Height 162 mm
- Size range
- Width 90–400 · Height 60–350 mm
- Manufacturing
- 229 × 162 mm score to score · inside vs outside sizes
- Parts
- One blank
- Board area
- 0.087 m² · about 4 up on a 720 × 1020 mm sheet
- Default board
- SBS white board 300 g · 0.42 mm caliper
- Board options
- SBS 300SBS 350Kraft 350GD2 350FBB 400Black 350Paper 170F-fluteSBS 18 pt
- Good for
The flat dieline
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed. How to read a dieline.
- Crease
- Cut
- Glue area
- Bleed 3 mm
How the blank is sized
Score-to-score panel sizes at the default size, with the formula each one follows. L, W and H are the inside dimensions; T is the board caliper (0.42 mm for SBS white board 300 g). Change the size or board in the editor and every panel is recalculated.
| Panel | Size (mm) | Formula |
|---|---|---|
| Front | 229 × 162 | L × H |
| Back | 229 × 160.7 | L × H − 1.3 |
| Side seal ×2 | 12 × 158.7 | – |
| Closing flap | 229 × 45.4 | L × – |
Adjustable in the editor
Beyond the size and board, this structure exposes 10 options; the template and 3D preview follow each change.
- Flap shape3 options
- Flap depthmm
- Peel & seal stripon / off
- Side seal widthmm
- Retained slit lockon / off
- Address windowon / off
- Thumb notchon / off
- Notch radiusmm
- Tear stripon / off
- Fastener3 options
Ready-sized board envelope presets
The same structure with sizes, boards and options set for a use.
