DM-FRAMED-FLAT-COVER-01Cards & tags
Framed window cover dieline
A shallow folding cover framing a broad window over an inner pocket, or a square card closed by four separate round petals. A ready-sized preset of the flat framed cover — change the length, width and height and every panel, tuck and glue flap is redrawn to match.
Inside160 × 160 mm
Outside161 × 161 mm
Flat blank478 × 160 mm
Download the dielinePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, cut, crease and bleed on separate layers, without a watermark. See plans
- Reference
- DM-FRAMED-FLAT-COVER-01
- Inside size
- Width 160 · Height 160 mm
- Size range
- Width 60–400 · Height 60–400 mm
- Manufacturing
- 160.5 × 160.5 mm score to score · inside vs outside sizes
- Parts
- One blank
- Board area
- 0.076 m² · about 6 up on a 720 × 1020 mm sheet
- Default board
- SBS white board 350 g · 0.5 mm caliper
- Board options
- SBS 350FBB 400Kraft 350Paper 170SBS 18 pt
- Good for
The flat dieline
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed. How to read a dieline.
- Crease
- Cut
- Bleed 3 mm
Adjustable in the editor
Beyond the size and board, this structure exposes 2 options; the template and 3D preview follow each change.
