DM-LABTUBE-01Labels
Self-standing centrifuge tube dieline
A clear screw-cap tube: round, flat, conical (centrifuge) or skirted bottom, glass or plastic, optionally holding one or two pre-rolls. Print the front label. A ready-sized preset of the screw-cap tube (lab / centrifuge / pre-roll) — change its size and the cut outline, bleed and safe area are redrawn to match.
InsideØ 29 × 115 mm
OutsideØ 29 × 115 mm
Flat blank54.7 × 54.4 mm
Download the dielinePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, cut, crease and bleed on separate layers, without a watermark. See plans
- Reference
- DM-LABTUBE-01
- Inside size
- Tube diameter 29 · Overall height 115 mm
- Size range
- Tube diameter 8–40 · Overall height 40–200 mm
- Manufacturing
- Ø 29 × 115 mm score to score · inside vs outside sizes
- Parts
- One blank
- Board area
- 0.003 m² · about 187 up on a 720 × 1020 mm sheet
- Default board
- Art paper 170 g · 0.16 mm caliper
- Board options
- Paper 170
- Good for
The flat dieline
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed. How to read a dieline.
- Cut
- Bleed 3 mm
Adjustable in the editor
Beyond the size and board, this structure exposes 6 options; the template and 3D preview follow each change.
- Bottom4 options
- Cap2 options
- Glass tubeon / off
- Print the cap topon / off
- Pre-rolls insidecount
- Cap colour6 options
The screw-cap tube (lab / centrifuge / pre-roll) family
