Preview image
The real blank at this size, folded by the same engine as the studio. The artwork is a sample from a fictional brand — swap in your own in the editor.
Parametric structureShapes
Nine-sided celebration box dieline
A fitted paperboard tray and lift-off lid with three to twelve sides. Changing the side count rebuilds the cap, every folding wall and its corner glue tabs. A ready-sized preset of the polygon tray & lid — change the length, width and height and every panel, tuck and glue flap is redrawn to match.
Inside190 × 190 × 50 mm
Outside191 × 191 × 51 mm
Flat blank290.6 × 290.1 mm
Download the dielinePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, cut, crease and bleed on separate layers, without a watermark. See plans
- Reference
- —
- Inside size
- Width 190 · Length 190 · Height 50 mm
- Size range
- Width 80–350 · Length 80–350 · Height 20–100 mm
- Manufacturing
- 190.5 × 190.5 × 50.5 mm score to score · inside vs outside sizes
- Parts
- 2 parts — Polygon tray & lid lid, Polygon tray & lid base tray
- Board area
- 0.100 m² · about 6 up on a 720 × 1020 mm sheet
- Default board
- SBS white board 350 g · 0.5 mm caliper
- Board options
- SBS 350FBB 400Kraft 350Black 350SBS 18 pt
- Good for
The flat dieline
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed. How to read a dieline.
- Crease
- Cut
- Glue area
- Bleed 3 mm
How the blank is sized
Score-to-score panel sizes at the default size, with the formula each one follows. L, W and H are the inside dimensions; T is the board caliper (0.5 mm for SBS white board 350 g). Change the size or board in the editor and every panel is recalculated.
| Panel | Size (mm) | Formula |
|---|---|---|
| Polygon tray & lid lidPolygon tray & lid lid | 155.1 × 100 | – |
| Polygon tray & lid wall ×2Polygon tray & lid lid | 17.5 × 67.7 | – |
| Corner glue tab ×2Polygon tray & lid lid | 10.9 × 4 | – |
| Polygon tray & lid wall ×2Polygon tray & lid lid | 17.5 × 67.9 | – |
| Corner glue tabPolygon tray & lid lid | 10.9 × 4.1 | – |
| Polygon tray & lid wall ×2Polygon tray & lid lid | 67.4 × 17.5 | – |
| Corner glue tabPolygon tray & lid lid | 4.2 × 10.9 | – |
| Polygon tray & lid wallPolygon tray & lid lid | 67 × 17.5 | – |
| Corner glue tabPolygon tray & lid lid | 4.2 × 10.9 | – |
| Corner glue tabPolygon tray & lid lid | 4.1 × 10.9 | – |
| Corner glue tabPolygon tray & lid lid | 10.9 × 4.1 | – |
| Polygon tray & lid wall ×2Polygon tray & lid lid | 67.1 × 17.5 | – |
| Corner glue tabPolygon tray & lid lid | 4.2 × 10.9 | – |
| Corner glue tabPolygon tray & lid lid | 4.1 × 10.9 | – |
| Pose rigPolygon tray & lid lid | 35.5 × 100 | – |
| Polygon tray & lid floorPolygon tray & lid base tray | 190.5 × 190.5 | – |
9 more panels are listed in the editor’s structure step.
Adjustable in the editor
Beyond the size and board, this structure exposes 2 options; the template and 3D preview follow each change.
- Lid depthmm
- Number of sidescount
The polygon tray & lid family
The same structure with sizes, boards and options set for a use.
Preset
Preset
Preset
Preset
Preset
Preset
Preset
Preset
Preset
