The real blank at this size, folded by the same engine as the studio. The artwork is a sample from a fictional brand — swap in your own in the editor.
ECMA F70.01.00.00Shapes
Hair extension pillow dieline
Long black pillow pack for a bundle of extensions. A ready-sized preset of the pillow box — change the length, width and height and every panel, tuck and glue flap is redrawn to match.
Inside250 × 110 × 30 mm
Outside251 × 110 × 31 mm
Flat blank231.5 × 279.9 mm
Download the dielinePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, cut, crease and bleed on separate layers, without a watermark. See plans
- Reference
- ECMA F70.01.00.00
- Inside size
- Length 250 · Width 110 · Depth 30 mm
- Size range
- Length 50–400 · Width 30–300 · Depth 6–120 mm
- Manufacturing
- 250.5 × 110 × 30.5 mm score to score · inside vs outside sizes
- Parts
- One blank
- Board area
- 0.060 m² · about 8 up on a 720 × 1020 mm sheet
- Default board
- Black-core board 350 g · 0.5 mm caliper
- Board options
- SBS 350SBS 300FBB 400Kraft 350Black 350PET 0.3SBS 18 pt
- Good for
The flat dieline
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed. How to read a dieline.
- Crease
- Cut
- Glue area
- Bleed 3 mm
How the blank is sized
Score-to-score panel sizes of this ECMA F70.01.00.00 blank at the default size, with the formula each one follows. L, W and H are the inside dimensions; T is the board caliper (0.5 mm for Black-core board 350 g). Change the size or board in the editor and every panel is recalculated.
| Panel | Size (mm) | Formula |
|---|---|---|
| Back strip 1 | 12.2 × 231.9 | – |
| Back top flap ×2 | 13.6 × 7 | – |
| Back bottom flap ×2 | 13.6 × 7 | – |
| Back strip 2 | 12.2 × 240.5 | – |
| Back top flap ×2 | 12.9 × 11.1 | – |
| Back bottom flap ×2 | 12.9 × 11.1 | – |
| Back strip 3 | 12.2 × 246 | – |
| Back top flap ×2 | 12.5 × 13.6 | – |
| Back bottom flap ×2 | 12.5 × 13.6 | – |
| Back strip 4 | 12.2 × 248.7 | – |
| Back top flap ×2 | 12.2 × 14.8 | – |
| Back bottom flap ×2 | 12.2 × 14.8 | – |
| Back strip 5 | 12.2 × 248.7 | (W − T) / 9 × L − H |
| Back top flap | 12.2 × 15.2 | – |
| Back bottom flap | 12.2 × 15.2 | – |
| Back strip 6 | 12.2 × 246 | – |
23 more panels are listed in the editor’s structure step.
Adjustable in the editor
Beyond the size and board, this structure exposes 4 options; the template and 3D preview follow each change.
- End flap depthmm
- Hang tabon / off
- Carry handleon / off
- Opening buttonholeon / off
The pillow box family
The same structure with sizes, boards and options set for a use.
Preset
Preset
Preset
Preset
Preset
Preset
Preset
Preset
Preset
Preset
Preset
Similar structures
Other structures built in a similar way, matched on code family, category, closures and proportions.
Make this hair extension pillow yours
Open it in the editor to set your size, drop artwork on each face, check bleed and safe areas, and export print-ready PDF with the dieline on its own layer — or stage it in a 3D scene for a mockup.
