Parametric structureCards & tags
A4 four-ring presentation binder dieline
A rigid front, spine and back with a continuous printed case wrap, matching inner liner and visible metal rings. Exports include the wrap with mitred turn-ins, liner and three board-cut references. Binding hardware, hinge gaps and punch positions must be confirmed with the binder maker. A ready-sized preset of the rigid ring binder — change its size and the cut outline, bleed and safe area are redrawn to match.
Inside265 × 60 × 315 mm
Outside265 × 60 × 315 mm
Flat blank640 × 351 mm
Download the dielinePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, cut, crease and bleed on separate layers, without a watermark. See plans
- Reference
- —
- Inside size
- Cover board width 265 · Spine board width 60 · Cover board height 315 mm
- Size range
- Cover board width 140–330 · Spine board width 25–80 · Cover board height 190–380 mm
- Manufacturing
- 265 × 60 × 315 mm score to score · inside vs outside sizes
- Parts
- 5 parts — Outer case wrap with turn-ins, Inner paper liner, back board · cut reference, spine board · cut reference, front board · cut reference
- Board area
- 0.595 m² · about 2 up on a 720 × 1020 mm sheet
- Default board
- Art paper 170 g · 0.16 mm caliper
- Board options
- Paper 170SBS 300SBS 18 pt
- Good for
The flat dieline
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed. How to read a dieline.
- Cut
- Bleed 3 mm
Adjustable in the editor
Beyond the size and board, this structure exposes 6 options; the template and 3D preview follow each change.
- Binder opening°
- Wrap turn-inmm
- Board hinge gapmm
- Clipfolio: spring clip on the front coveron / off
- Ring mechanism3 options
- Ring shape2 options
