Contoured flexible sachet dieline
Two matching contour-cut film webs with rounded shoulders, a narrowed waist and a continuous heat-seal band. Tear notches remain within the seal. The inflated mockup follows the same film outline; this packet has no bottom gusset. Fill weights are editable examples, and barrier, hot-fill or retort suitability requires the laminate supplier’s specification. A parametric template — change its size and the cut outline, bleed and safe area are redrawn to match.
Inside70 × 130 mm
Outside70 × 130 mm
Flat blank70 × 130 mm
Download the dielinePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, cut, crease and bleed on separate layers, without a watermark. See plans
- Reference
- —
- Inside size
- Maximum flat width 70 · Film height 130 mm
- Size range
- Maximum flat width 50–180 · Film height 80–260 mm
- Manufacturing
- 70 × 130 mm score to score · inside vs outside sizes
- Parts
- 2 parts — Front contour-cut web, Back contour-cut web
- Board area
- 0.016 m² · about 65 up on a 720 × 1020 mm sheet
- Default board
- White PET / PE laminate · 0.09 mm caliper
- Board options
- White PET/PEMet PET/PEClear PET/PEKraft/PE
- Good for
The flat dieline
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed. How to read a dieline.
- Cut
- Bleed 3 mm
Adjustable in the editor
Beyond the size and board, this structure exposes 7 options; the template and 3D preview follow each change.
- Outline2 options
- Continuous seal widthmm
- Shoulder insetmm
- Waist insetmm
- Tear notcheson / off
- Notch from topmm
- Preview fill%
