The real blank at this size, folded by the same engine as the studio. The artwork is a sample from a fictional brand — swap in your own in the editor.
Parametric structureSleeves
Pocket book slipcase — Slipcase dieline
Editable 115 × 25 × 185 mm starting point using slipcase. Adjust the dimensions to your product before prototyping. A ready-sized preset of the slipcase — change the length, width and height and every panel, tuck and glue flap is redrawn to match.
Inside115 × 25 × 185 mm
Outside115.5 × 26 × 186 mm
Flat blank256 × 260.5 mm
Download the dielinePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, cut, crease and bleed on separate layers, without a watermark. See plans
- Reference
- —
- Inside size
- Length 115 · Width 25 · Height 185 mm
- Size range
- Length 60–400 · Width 8–200 · Height 60–450 mm
- Manufacturing
- 115.3 × 25.5 × 185.5 mm score to score · inside vs outside sizes
- Parts
- One blank
- Board area
- 0.054 m² · about 6 up on a 720 × 1020 mm sheet
- Default board
- SBS white board 350 g · 0.5 mm caliper
- Board options
- SBS 350FBB 400Black 350Kraft 350GD2 350F-fluteE-flute WSBS 18 pt
- Good for
The flat dieline
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed. How to read a dieline.
- Crease
- Cut
- Glue area
- Bleed 3 mm
How the blank is sized
Score-to-score panel sizes at the default size, with the formula each one follows. L, W and H are the inside dimensions; T is the board caliper (0.5 mm for SBS white board 350 g). Change the size or board in the editor and every panel is recalculated.
| Panel | Size (mm) | Formula |
|---|---|---|
| Front | 115.3 × 185.5 | L + T/2 × H + T |
| Spine | 25.5 × 184.5 | W + T × H − T |
| Back | 115.3 × 184.5 | L + T/2 × H − T |
| Top | 115.3 × 25.5 | L + T/2 × W + T |
| Glue tab ×2 | 100.3 × 12 | – |
| Spine ear ×2 | 23.5 × 12 | – |
| Bottom | 115.3 × 25.5 | L + T/2 × W + T |
