A 3D product preview with editable artwork placement. The downloads contain artwork areas; manufacturing patterns and hardware drawings are not included. The artwork is a sample from a fictional brand — swap in your own in the editor.
Artwork placementLabels
Square glass candle label template
Rounded rectangular glass walls rise to a circular screw neck and lid. Front and back labels are separate flat pieces; these artwork templates are not glass mould drawings. A ready-sized preset of the square glass jar — adjust the object dimensions and decoration area to preview your artwork at size.
Object size80 × 80 × 95 mm
Artwork area58 × 76 mm
Download the artwork templatePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, with the artwork area and bleed, without a watermark. See plans
- Reference
- —
- Object size
- Body width 80 · Body depth 80 · Overall height 95 mm
- Size range
- Body width 45–220 · Body depth 35–180 · Overall height 25–220 mm
- Parts
- 2 parts — Front label, Back label
- Artwork area
- 0.009 m²
- Good for
The flat artwork area
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed.
- Artwork boundary
- Bleed 3 mm
Adjustable in the editor
Alongside dimensions, the template offers 11 options; the template and 3D preview follow each change.
- Label width (0 = auto)mm
- Label height (0 = auto)mm
- Back labelon / off
- Body colour10 options
- Cap colour10 options
- Lid labelon / off
- Contents preview4 options
- Use2 options
- Wax colour6 options
- Wax level%
- Body material3 options
The square glass jar family
The same model with sizes and artwork options ready to customize.
