Preview image
The real blank at this size, folded by the same engine as the studio. The artwork is a sample from a fictional brand — swap in your own in the editor.
Parametric structureCards & tags
Twelve-card palette book dieline
Build a fan of individually printed sample cards or one folded cover blank with paired holes, return panels or an open hanger aperture. Fan cards export separately; folded covers export as one two-sided board part. Samples and hardware for the covers are supplied separately; confirm fastener fit and stock performance with a physical prototype. A ready-sized preset of the swatch books and folded covers — change its size and the cut outline, bleed and safe area are redrawn to match.
Inside55 × 150 mm
Outside55 × 150 mm
Flat blank55 × 150 mm
Download the dielinePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, cut, crease and bleed on separate layers, without a watermark. See plans
- Reference
- —
- Inside size
- Card / cover width 55 · Card / cover height 150 mm
- Size range
- Card / cover width 40–400 · Card / cover height 60–300 mm
- Manufacturing
- 55 × 150 mm score to score · inside vs outside sizes
- Parts
- 12 parts — Sample card 1, Sample card 2, Sample card 3, Sample card 4, Sample card 5, Sample card 6, Sample card 7, Sample card 8, Sample card 9, Sample card 10, Sample card 11, Sample card 12
- Board area
- 0.099 m² · about 66 up on a 720 × 1020 mm sheet
- Default board
- SBS white board 350 g · 0.5 mm caliper
- Board options
- SBS 350SBS 300Kraft 350SBS 18 pt
- Good for
The flat dieline
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed. How to read a dieline.
- Cut
- Bleed 3 mm
Adjustable in the editor
Beyond the size and board, this structure exposes 4 options; the template and 3D preview follow each change.
- Construction4 options
- Cardscount
- Fan spread°
- Binding hole diametermm
The swatch books and folded covers family
The same structure with sizes, boards and options set for a use.
Preset
Preset
Preset
Preset
Preset
Preset
Preset
Preset
Preset
Preset
Preset
Similar structures
Other structures built in a similar way, matched on code family, category, closures and proportions.
Make this twelve-card palette book yours
Open it in the editor to set your size, drop artwork on each face, check bleed and safe areas, and export print-ready PDF with the dieline on its own layer — or stage it in a 3D scene for a mockup.
