Preview image
The real blank at this size, folded by the same engine as the studio. The artwork is a sample from a fictional brand — swap in your own in the editor.
Parametric structureCarriers
Eight-cup grid carrier dieline
Two columns across four rows for a broad bulk-order deck. A ready-sized preset of the cup carrier — change the length, width and height and every panel, tuck and glue flap is redrawn to match.
Inside190 × 360 × 200 mm
Outside191.2 × 361.2 × 200 mm
Flat blank289.4 × 1120 mm
Download the dielinePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, cut, crease and bleed on separate layers, without a watermark. See plans
- Reference
- —
- Inside size
- Length 190 · Depth 360 · Height 200 mm
- Size range
- Length 70–600 · Depth 90–600 · Height 70–320 mm
- Manufacturing
- 190.6 × 360.6 × 200 mm score to score · inside vs outside sizes
- Parts
- One blank
- Board area
- 0.265 m²
- Default board
- Folding boxboard 400 g · 0.6 mm caliper
- Board options
- Kraft 350FBB 400SBS 350F-fluteSBS 18 pt
- Good for
The flat dieline
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed. How to read a dieline.
- Reverse crease
- Crease
- Cut
- Glue area
- Bleed 3 mm
How the blank is sized
Score-to-score panel sizes at the default size, with the formula each one follows. L, W and H are the inside dimensions; T is the board caliper (0.6 mm for Folding boxboard 400 g). Change the size or board in the editor and every panel is recalculated.
| Panel | Size (mm) | Formula |
|---|---|---|
| Base | 190.6 × 360.6 | L + T × W + T |
| Front | 190.6 × 50 | L + T × deck |
| Back | 190.6 × 50 | L + T × deck |
| Front corner ear ×2 | 45 × 48.8 | – |
| Back corner ear ×2 | 45 × 48.8 | – |
| Right side | 49.4 × 359.4 | W − T × deck − T |
| Left side | 49.4 × 359.4 | W − T × deck − T |
| Front deck | 190.6 × 179.7 | L + T × W/2 − T/2 |
| Back deck | 190.6 × 179.7 | L + T × W/2 − T/2 |
| Deck glue flap ×4 | 22.2 × 178.6 | – |
| Front handle | 190.6 × 150 | L + T × H − deck |
| Back handle | 190.6 × 150 | L + T × H − deck |
Adjustable in the editor
Beyond the size and board, this structure exposes 8 options; the template and 3D preview follow each change.
- Requested cupscount
- Cup rowscount
- Cups per rowcount
- Cup diametermm
- Deck heightmm
- Grip tabsmm
- Hand holeon / off
- Hole widthmm
