Preview image
The real blank at this size, folded by the same engine as the studio. The artwork is a sample from a fictional brand — swap in your own in the editor.
Parametric structureBags & pouches
Tea biscuit pillow wrap, 165 mm film dieline
A 175 mm cut-off on a 165 mm film web around a 137 × 53 × 18 mm biscuit stack: back fin seal, crimped serrated ends. The film width is not the finished pack width; confirm seals and cut-off with the converter. A ready-sized preset of the flow wrap — change the length, width and height and every panel, tuck and glue flap is redrawn to match.
Inside137 × 53 × 18 mm
Outside137 × 53 × 18 mm
Flat blank176.5 × 165 mm
Download the dielinePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, cut, crease and bleed on separate layers, without a watermark. See plans
- Reference
- —
- Inside size
- Product length 137 · Product width 53 · Product height 18 mm
- Size range
- Product length 30–400 · Product width 8–250 · Product height 3–150 mm
- Manufacturing
- 137 × 53 × 18 mm score to score · inside vs outside sizes
- Parts
- One blank
- Board area
- 0.029 m² · about 20 up on a 720 × 1020 mm sheet
- Default board
- Metallised PET / PE laminate · 0.09 mm caliper
- Board options
- Met PET/PEWhite PET/PEClear PET/PEKraft/PE
- Good for
The flat dieline
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed. How to read a dieline.
- Cut
- Bleed 3 mm
How the blank is sized
Score-to-score panel sizes at the default size, with the formula each one follows. L, W and H are the inside dimensions; T is the board caliper (0.09 mm for Metallised PET / PE laminate). Change the size or board in the editor and every panel is recalculated.
| Panel | Size (mm) | Formula |
|---|---|---|
| Fin seal (inner) | 176.5 × 10 | – |
| Back (upper half) | 176.5 × 26.5 | – |
| Top | 176.5 × 19.5 | – |
| Front | 176.5 × 53 | – × W |
| Bottom | 176.5 × 19.5 | – |
| Back (lower half) | 176.5 × 26.5 | – |
| Fin seal (outer) | 176.5 × 10 | – |
Adjustable in the editor
Beyond the size and board, this structure exposes 6 options; the template and 3D preview follow each change.
- Longitudinal seal2 options
- Long seal widthmm
- End sealsmm
- Product shape2 options
- Orientation2 options
- End cut2 options
The flow wrap family
The same structure with sizes, boards and options set for a use.
Preset
Preset
Preset
Preset
Preset
Preset
Preset
Preset
Preset
Preset
Preset
Inspired by customer briefs
See where an idea can go.
Original concepts with fictional brands, paired with native templates you can open and customize.
OATBOUND
Find your good morning.
The request
- Create cereal-bar packaging across individual wrappers, multipacks and retail displays.
Choose your starting point
Choose the format for the job: a fin- or lap-seal wrapper, a glued-end multipack carton, or a display tray. Set product dimensions, count and arrangement, then confirm film or board, seals and closure with the supplier. Example sizes remain editable.
Explore the actual templates
Native geometry and sample artwork below. The generated scene is creative direction; its artwork and construction may differ.
Before you choose this template
Size, materials, downloads and production checks.
Will the tea biscuit pillow wrap, 165 mm film dieline fit my product?
A 175 mm cut-off on a 165 mm film web around a 137 × 53 × 18 mm biscuit stack: back fin seal, crimped serrated ends. The film width is not the finished pack width; confirm seals and cut-off with the converter. The default dimensions in inside-size mode are Product length 137 mm, Product width 53 mm, Product height 18 mm. Measure your product and any inserts or wrapping, then set the template size. Check a physical sample with your contents before ordering production.
Can I change the size and design?
Yes. The supported ranges are Product length 30–400 mm, Product width 8–250 mm, Product height 3–150 mm. At the default settings, the editor also exposes Longitudinal seal, Long seal width, End seals, Product shape, Orientation, End cut. Add your own artwork and preview the result in 3D. The template geometry is rebuilt when its dimensions change.
Which materials can I choose?
The default is Metallised PET / PE laminate (0.09 mm caliper). This structure allows Metallised PET / PE laminate, White PET / PE laminate, Clear PET / PE laminate, Kraft paper / PE laminate. Select the stock before checking fit, and ask your converter to confirm the grade and caliper for the intended product.
Which files can I download?
The template page offers dimensioned PDF, Illustrator (.ai via script), layered SVG and DXF cutting and crease geometry. After adding artwork in the editor, you can export a print-ready PDF and review the bleed, safe areas and dieline layers with your printer.
Is this dieline free?
Browsing the previews is free, and you can customize the template after signing in with Google. Template and print-file downloads require a Pro or Business plan. The Free plan allows one eligible download every 8 hours; free mockups, renders and videos carry a watermark. See the pricing page for the current plans.
Can I send the download straight to production?
Use the file as a starting point for a printer or converter review. Confirm the finished dimensions, stock, crease and cutting setup, assembly, bleed and artwork, then approve a physical sample. The 3D preview does not test strength, transit performance or suitability for particular contents.
