Preview image
The real blank at this size, folded by the same engine as the studio. The artwork is a sample from a fictional brand — swap in your own in the editor.
Parametric structureBags & pouches
Windowed bread satchel dieline
An open-mouth paper food bag with a glued longitudinal seam and folded pinch / V bottom. Set the side gusset to zero for a flat bag or add gussets for a bread satchel. The optional cut window has a separate clear backing piece. Use converter-approved greaseproof or barrier-coated food-contact paper, compatible adhesive and suitable window film; the selectable art paper and kraft stocks are preview references. Check conversion, bottom closure and product compatibility with the supplier. A ready-sized preset of the flat / satchel paper food bag — change the length, width and height and every panel, tuck and glue flap is redrawn to match.
Inside125 × 355 mm
Outside125 × 355 mm
Flat blank362 × 375 mm
Download the dielinePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, cut, crease and bleed on separate layers, without a watermark. See plans
- Reference
- —
- Inside size
- Face width 125 · Finished bag height 355 mm
- Size range
- Face width 80–350 · Finished bag height 100–650 mm
- Manufacturing
- 125 × 355 mm score to score · inside vs outside sizes
- Parts
- 2 parts — Paper bag conversion web, Clear window backing film
- Board area
- 0.148 m² · about 2 up on a 720 × 1020 mm sheet
- Default board
- Art paper 170 g · 0.16 mm caliper
- Board options
- Paper 170Kraft 350
- Good for
The flat dieline
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed. How to read a dieline.
- Crease
- Cut
- Glue area
- Bleed 3 mm
How the blank is sized
Score-to-score panel sizes at the default size, with the formula each one follows. L, W and H are the inside dimensions; T is the board caliper (0.16 mm for Art paper 170 g). Change the size or board in the editor and every panel is recalculated.
| Panel | Size (mm) | Formula |
|---|---|---|
| FrontPaper bag conversion web | 125 × 370 | L × – |
| Right gussetPaper bag conversion web | 50 × 370 | – |
| Back with mouth lipPaper bag conversion web | 125 × 370 | L × – |
| Left gussetPaper bag conversion web | 50 × 370 | – |
| Longitudinal glue lapPaper bag conversion web | 12 × 370 | – |
| Unprinted window backingClear window backing film | 67 × 202 | – |
Adjustable in the editor
Beyond the size and board, this structure exposes 9 options; the template and 3D preview follow each change.
- Opened side gussetmm
- Longitudinal glue lapmm
- Pinch bottom foldmm
- Extended back mouth lipmm
- Clear-backed cut windowon / off
- Window widthmm
- Window heightmm
- Mouth closure2 options
- Preview opening%
The flat / satchel paper food bag family
The same structure with sizes, boards and options set for a use.
Preset
Preset
Preset
Similar structures
Other structures built in a similar way, matched on code family, category, closures and proportions.
Make this windowed bread satchel yours
Open it in the editor to set your size, drop artwork on each face, check bleed and safe areas, and export print-ready PDF with the dieline on its own layer — or stage it in a 3D scene for a mockup.
