The real blank at this size, folded by the same engine as the studio. The artwork is a sample from a fictional brand — swap in your own in the editor.
Parametric structureShapes
Shaped jewellery set box — Rhombus tray & lid dieline
Editable 140 × 120 × 38 mm starting point using rhombus tray & lid. Adjust the dimensions to your product before prototyping. A ready-sized preset of the rhombus tray & lid — change the length, width and height and every panel, tuck and glue flap is redrawn to match.
Inside140 × 120 × 38 mm
Outside141 × 121 × 39 mm
Flat blank200.8 × 186.8 mm
Download the dielinePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, cut, crease and bleed on separate layers, without a watermark. See plans
- Reference
- —
- Inside size
- Width 140 · Length 120 · Height 38 mm
- Size range
- Width 80–350 · Length 80–350 · Height 20–100 mm
- Manufacturing
- 140.5 × 120.5 × 38.5 mm score to score · inside vs outside sizes
- Parts
- 2 parts — Rhombus tray & lid lid, Rhombus tray & lid base tray
- Board area
- 0.038 m² · about 18 up on a 720 × 1020 mm sheet
- Default board
- SBS white board 350 g · 0.5 mm caliper
- Board options
- SBS 350FBB 400Kraft 350Black 350SBS 18 pt
- Good for
The flat dieline
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed. How to read a dieline.
- Crease
- Cut
- Glue area
- Bleed 3 mm
How the blank is sized
Score-to-score panel sizes at the default size, with the formula each one follows. L, W and H are the inside dimensions; T is the board caliper (0.5 mm for SBS white board 350 g). Change the size or board in the editor and every panel is recalculated.
| Panel | Size (mm) | Formula |
|---|---|---|
| Rhombus tray & lid lidRhombus tray & lid lid | 100 × 58.8 | – |
| Rhombus tray & lid wall ×4Rhombus tray & lid lid | 94.9 × 15 | – |
| Corner glue tab ×4Rhombus tray & lid lid | 4.5 × 9.2 | – |
| Pose rigRhombus tray & lid lid | 100 × 35 | – |
| Rhombus tray & lid floorRhombus tray & lid base tray | 140.8 × 120.7 | – |
| Rhombus tray & lid wall ×4Rhombus tray & lid base tray | 92.7 × 38.5 | – × H + T |
| Corner glue tab ×4Rhombus tray & lid base tray | 10 × 24.5 | – |
Adjustable in the editor
Beyond the size and board, this structure exposes 1 option; the template and 3D preview follow each change.
- Lid depthmm
