Diamond wedding favour dieline
A diamond-plan tray with four oblique corners and a separate fitted lid. Wall panels fold from each cap and hand-glued corner tabs close the sides. A ready-sized preset of the rhombus tray & lid — change the length, width and height and every panel, tuck and glue flap is redrawn to match.
Inside100 × 145 × 30 mm
Outside101 × 146 × 31 mm
Flat blank156.6 × 191.2 mm
Download the dielinePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, cut, crease and bleed on separate layers, without a watermark. See plans
- Reference
- —
- Inside size
- Width 100 · Length 145 · Height 30 mm
- Size range
- Width 80–350 · Length 80–350 · Height 20–100 mm
- Manufacturing
- 100.5 × 145.5 × 30.5 mm score to score · inside vs outside sizes
- Parts
- 2 parts — Rhombus tray & lid lid, Rhombus tray & lid base tray
- Board area
- 0.030 m² · about 23 up on a 720 × 1020 mm sheet
- Default board
- SBS white board 350 g · 0.5 mm caliper
- Board options
- SBS 350FBB 400Kraft 350Black 350SBS 18 pt
- Good for
The flat dieline
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed. How to read a dieline.
- Crease
- Cut
- Glue area
- Bleed 3 mm
How the blank is sized
Score-to-score panel sizes at the default size, with the formula each one follows. L, W and H are the inside dimensions; T is the board caliper (0.5 mm for SBS white board 350 g). Change the size or board in the editor and every panel is recalculated.
| Panel | Size (mm) | Formula |
|---|---|---|
| Rhombus tray & lid lidRhombus tray & lid lid | 50 × 100 | – |
| Rhombus tray & lid wall ×4Rhombus tray & lid lid | 10.5 × 91 | – |
| Corner glue tab ×4Rhombus tray & lid lid | 6.3 × 3.2 | – |
| Pose rigRhombus tray & lid lid | 35 × 100 | – |
| Rhombus tray & lid floorRhombus tray & lid base tray | 100.6 × 145.9 | – |
| Rhombus tray & lid wall ×4Rhombus tray & lid base tray | 30.5 × 88.6 | H + T × – |
| Corner glue tab ×4Rhombus tray & lid base tray | 19.3 × 9.2 | – |
Adjustable in the editor
Beyond the size and board, this structure exposes 1 option; the template and 3D preview follow each change.
- Lid depthmm
