Preview image
The real blank at this size, folded by the same engine as the studio. The artwork is a sample from a fictional brand — swap in your own in the editor.
FEFCO 0713Shipping
Subscription box 300×220×110 dieline
White printed box that erects in one move on a busy packing bench. A ready-sized preset of the crash-lock tuck-top box — change the length, width and height and every panel, tuck and glue flap is redrawn to match.
Inside300 × 220 × 110 mm
Outside303.2 × 223.2 × 116.4 mm
Flat blank1064.8 × 491.8 mm
Download the dielinePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, cut, crease and bleed on separate layers, without a watermark. See plans
- Reference
- FEFCO 0713
- Inside size
- Length 300 · Width 220 · Height 110 mm
- Size range
- Length 80–800 · Width 50–600 · Height 50–800 mm
- Manufacturing
- 301.6 × 221.6 × 113.2 mm score to score · inside vs outside sizes
- Parts
- One blank
- Board area
- 0.353 m²
- Default board
- E-flute white / kraft · 1.6 mm caliper
- Board options
- E-flute WE-flute KB-fluteF-fluteEB double
- Good for
The flat dieline
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed. How to read a dieline.
- Reverse crease
- Crease
- Cut
- Glue area
- Bleed 3 mm
How the blank is sized
Score-to-score panel sizes of this FEFCO 0713 blank at the default size, with the formula each one follows. L, W and H are the inside dimensions; T is the board caliper (1.6 mm for E-flute white / kraft). Change the size or board in the editor and every panel is recalculated.
| Panel | Size (mm) | Formula |
|---|---|---|
| Front | 301.6 × 113.2 | L + T × H + 2T |
| Left side | 221.6 × 113.2 | W + T × H + 2T |
| Back | 301.6 × 113.2 | L + T × H + 2T |
| Right side | 220 × 113.2 | W × H + 2T |
| Glue flap | 20 × 113.2 | – × H + 2T |
| Crash-lock flap (back) | 301.6 × 133.8 | L + T × – |
| Glued web | 156.7 × 77.9 | – |
| Bottom side flap | 221.6 × 110 | W + T × – |
| Crash-lock flap (front) | 301.6 × 133.8 | L + T × – |
| Glued web | 77.9 × 156.7 | – |
| Bottom side flap | 220 × 110 | W × – |
| Top closure | 301.6 × 218.4 | L + T × W − T |
| Top tuck | 298.4 × 26.4 | L − T × – |
| Top dust flap | 214.2 × 123.2 | – |
| Top dust flap | 212.6 × 123.2 | – |
Adjustable in the editor
Beyond the size and board, this structure exposes 4 options; the template and 3D preview follow each change.
- Tuck depthmm
- Thumb notchon / off
- Hook reachmm
- Hook notchmm
