FEFCO 0602Shipping
Rigid box with separate ends dieline
Source-specific sleeve and rigid-box constructions with separate printable blanks, specified opening directions and board allowances. A parametric template — change the length, width and height and every panel, tuck and glue flap is redrawn to match.
Inside400 × 260 × 150 mm
Outside406.4 × 263.2 × 153.2 mm
Flat blank461.6 × 886.4 mm
Download the dielinePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, cut, crease and bleed on separate layers, without a watermark. See plans
- Reference
- FEFCO 0602
- Inside size
- Length 400 · Width 260 · Height 150 mm
- Size range
- Length 120–1000 · Width 80–700 · Height 40–500 mm
- Manufacturing
- 401.6 × 261.6 × 151.6 mm score to score · inside vs outside sizes
- Parts
- 3 parts — body, left end, right end
- Board area
- 0.477 m² · about 1 up on a 720 × 1020 mm sheet
- Default board
- E-flute kraft / kraft · 1.6 mm caliper
- Board options
- E-flute KE-flute WB-fluteSBS 350SBS 18 pt
- Good for
The flat dieline
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed. How to read a dieline.
- Crease
- Cut
- Glue area
- Bleed 3 mm
How the blank is sized
Score-to-score panel sizes of this FEFCO 0602 blank at the default size, with the formula each one follows. L, W and H are the inside dimensions; T is the board caliper (1.6 mm for E-flute kraft / kraft). Change the size or board in the editor and every panel is recalculated.
| Panel | Size (mm) | Formula |
|---|---|---|
| Bottombody | 401.6 × 261.6 | L + T × W + T |
| frontbody | 401.6 × 151.6 | L + T × H + T |
| backbody | 401.6 × 151.6 | L + T × H + T |
| top frontbody | 401.6 × 30 | L + T × – |
| top backbody | 401.6 × 261.6 | L + T × W + T |
| lid tuckbody | 401.6 × 30 | L + T × – |
| front left gluebody | 30 × 148.4 | – × H − T |
| front right gluebody | 30 × 148.4 | – × H − T |
| bottom left gluebody | 30 × 261.6 | – × W + T |
| bottom right gluebody | 30 × 261.6 | – × W + T |
| back left gluebody | 30 × 148.4 | – × H − T |
| back right gluebody | 30 × 148.4 | – × H − T |
| Pose rigleft end | 100 × 35 | – |
| left endleft end | 100 × 116.6 | – |
| n glueleft end | 261.6 × 30 | W + T × – |
| Pose rigright end | 100 × 35 | – |
2 more panels are listed in the editor’s structure step.
Adjustable in the editor
Beyond the size and board, this structure exposes 3 options; the template and 3D preview follow each change.
- Construction9 options
- Glue or tuck depthmm
- 0605 cover depthmm
