Preview image
The real blank at this size, folded by the same engine as the studio. The artwork is a sample from a fictional brand — swap in your own in the editor.
ECMA F80.21.00.00Trays & lids
Bottle and leaflet insert 90×60×200 dieline
A main compartment for a bottle and a narrow one for its leaflet. A ready-sized preset of the folded compartment insert — change the length, width and height and every panel, tuck and glue flap is redrawn to match.
Inside90 × 60 × 200 mm
Outside90.9 × 60.9 × 200 mm
Flat blank425.1 × 200 mm
Download the dielinePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, cut, crease and bleed on separate layers, without a watermark. See plans
- Reference
- ECMA F80.21.00.00
- Inside size
- Length 90 · Width 60 · Height 200 mm
- Size range
- Length 40–600 · Width 30–400 · Height 20–400 mm
- Manufacturing
- 90.5 × 60.5 × 200 mm score to score · inside vs outside sizes
- Parts
- One blank
- Board area
- 0.085 m² · about 4 up on a 720 × 1020 mm sheet
- Default board
- Kraft board 350 g · 0.46 mm caliper
- Board options
- SBS 350Kraft 350FBB 400GD2 350F-fluteE-flute KE-flute WSBS 18 pt
- Good for
The flat dieline
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed. How to read a dieline.
- Crease
- Cut
- Glue area
- Bleed 3 mm
How the blank is sized
Score-to-score panel sizes of this ECMA F80.21.00.00 blank at the default size, with the formula each one follows. L, W and H are the inside dimensions; T is the board caliper (0.46 mm for Kraft board 350 g). Change the size or board in the editor and every panel is recalculated.
| Panel | Size (mm) | Formula |
|---|---|---|
| End wall ×2 | 60.5 × 200 | W + T × H |
| Side wall | 90.5 × 200 | L + T × H |
| Side wall | 90 × 200 | L × H |
| Spacer | 18 × 200 | – × H |
| Divider | 89.1 × 200 | L − 2T × H |
| Glue flap | 16.6 × 200 | – × H |
Adjustable in the editor
Beyond the size and board, this structure exposes 2 options; the template and 3D preview follow each change.
- Compartments2 options
- First compartmentmm
The folded compartment insert family
The same structure with sizes, boards and options set for a use.
Preset
Preset
Similar structures
Other structures built in a similar way, matched on code family, category, closures and proportions.
Make this bottle and leaflet insert 90×60×200 yours
Open it in the editor to set your size, drop artwork on each face, check bleed and safe areas, and export print-ready PDF with the dieline on its own layer — or stage it in a 3D scene for a mockup.
