A 3D product preview with editable artwork placement. The downloads contain artwork areas; manufacturing patterns and hardware drawings are not included. The artwork is a sample from a fictional brand — swap in your own in the editor.
Artwork placementLabels
Kitchen storage jar 1 L label template
A square glass storage jar with a glass lid, rubber gasket and actual wire-bail latch. Exports are its front and back labels; glass, sealing performance and latch tooling require the supplier’s drawing. A ready-sized preset of the wire-bail storage jar — adjust the object dimensions and decoration area to preview your artwork at size.
Object size122 × 115 × 190 mm
Artwork area100 × 127.2 mm
Download the artwork templatePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, with the artwork area and bleed, without a watermark. See plans
- Reference
- —
- Object size
- Body width 122 · Body depth 115 · Overall height 190 mm
- Size range
- Body width 60–180 · Body depth 60–180 · Overall height 85–260 mm
- Parts
- 2 parts — Front label, Back label
- Artwork area
- 0.025 m²
- Good for
The flat artwork area
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed.
- Artwork boundary
- Bleed 3 mm
Adjustable in the editor
Alongside dimensions, the template offers 6 options; the template and 3D preview follow each change.
- Label width (0 = auto)mm
- Label height (0 = auto)mm
- Back labelon / off
- Body colour10 options
- Contents preview4 options
- Body material3 options
The wire-bail storage jar family
The same model with sizes and artwork options ready to customize.
Preset
Preset
Preset
Preset
Preset
Preset
Preset
Similar structures
Other structures built in a similar way, matched on code family, category, closures and proportions.
Make this kitchen storage jar 1 l yours
Set the artwork area, add your design and export the dimensioned artwork template, or stage the product in a 3D scene.
