Clip-top preserve jar label template
A square glass storage jar with a glass lid, rubber gasket and actual wire-bail latch. Exports are its front and back labels; glass, sealing performance and latch tooling require the supplier’s drawing. A ready-sized preset of the wire-bail storage jar — adjust the object dimensions and decoration area to preview your artwork at size.
Object size108 × 100 × 165 mm
Artwork area86 × 107.2 mm
Download the artwork templatePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, with the artwork area and bleed, without a watermark. See plans
- Reference
- —
- Object size
- Body width 108 · Body depth 100 · Overall height 165 mm
- Size range
- Body width 60–180 · Body depth 60–180 · Overall height 85–260 mm
- Parts
- 2 parts — Front label, Back label
- Artwork area
- 0.018 m²
- Good for
The flat artwork area
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed.
- Artwork boundary
- Bleed 3 mm
