Preview image
The real blank at this size, folded by the same engine as the studio. The artwork is a sample from a fictional brand — swap in your own in the editor.
DM-SCOOP-01Labels
Scoop with funnel dieline
A plastic measuring scoop with a round cup and flat handle, flat-bottomed or with a funnel spout. Print the handle top or a band round the cup. A ready-sized preset of the powder measuring scoop — change its size and the cut outline, bleed and safe area are redrawn to match.
Inside60 × 90 × 45 mm
Outside60 × 90 × 45 mm
Flat blank94.2 × 22.5 mm
Download the dielinePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, cut, crease and bleed on separate layers, without a watermark. See plans
- Reference
- DM-SCOOP-01
- Inside size
- Cup diameter 60 · Handle length 90 · Cup depth 45 mm
- Size range
- Cup diameter 20–120 · Handle length 30–200 · Cup depth 10–100 mm
- Manufacturing
- 60 × 90 × 45 mm score to score · inside vs outside sizes
- Parts
- 2 parts — Handle top, Cup band (front half)
- Board area
- 0.003 m² · about 250 up on a 720 × 1020 mm sheet
- Default board
- Art paper 170 g · 0.16 mm caliper
- Board options
- Paper 170
- Good for
The flat dieline
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed. How to read a dieline.
- Cut
- Bleed 3 mm
Adjustable in the editor
Beyond the size and board, this structure exposes 3 options; the template and 3D preview follow each change.
- Bottom2 options
- Print zone3 options
- Colour6 options
The powder measuring scoop family
The same structure with sizes, boards and options set for a use.
Preset
Preset
Preset
Similar structures
Other structures built in a similar way, matched on code family, category, closures and proportions.
Make this scoop with funnel yours
Open it in the editor to set your size, drop artwork on each face, check bleed and safe areas, and export print-ready PDF with the dieline on its own layer — or stage it in a 3D scene for a mockup.
