Rectangular metal tin label template
Pressed rectangular metal tin with a rolled rim and a separate slip lid or an attached rear-hinged lid. The hinged lid opens with its own artwork. Exports provide front, back and lid graphic areas; exact tinplate forming tools, hinge construction and food-contact coatings require the maker’s drawing. A parametric template — adjust the object dimensions and decoration area to preview your artwork at size.
Object size130 × 85 × 46 mm
Artwork area112 × 67 mm
Download the artwork templatePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, with the artwork area and bleed, without a watermark. See plans
- Reference
- —
- Object size
- Body width 130 · Body depth 85 · Overall height 46 mm
- Size range
- Body width 45–220 · Body depth 35–180 · Overall height 25–220 mm
- Parts
- 3 parts — Front label, Back label, Lid label
- Artwork area
- 0.013 m²
