Preview image
The real blank at this size, folded by the same engine as the studio. The artwork is a sample from a fictional brand — swap in your own in the editor.
Parametric structureSleeves
DVD gatefold wallet dieline
Wallet the size of a DVD keep case, so it shelves with them: a disc pocket and a booklet pocket. A ready-sized preset of the record jacket — change the length, width and height and every panel, tuck and glue flap is redrawn to match.
Inside133 × 188 mm
Outside133.5 × 189 mm
Flat blank528.5 × 212.5 mm
Download the dielinePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, cut, crease and bleed on separate layers, without a watermark. See plans
- Reference
- —
- Inside size
- Width 133 · Height 188 mm
- Size range
- Width 80–340 · Height 80–340 mm
- Manufacturing
- 133.3 × 188.5 mm score to score · inside vs outside sizes
- Parts
- One blank
- Board area
- 0.104 m² · about 4 up on a 720 × 1020 mm sheet
- Default board
- SBS white board 350 g · 0.5 mm caliper
- Board options
- SBS 350SBS 300FBB 400Kraft 350Black 350GD2 350SBS 18 pt
- Good for
The flat dieline
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed. How to read a dieline.
- Crease
- Cut
- Glue area
- Bleed 3 mm
How the blank is sized
Score-to-score panel sizes at the default size, with the formula each one follows. L, W and H are the inside dimensions; T is the board caliper (0.5 mm for SBS white board 350 g). Change the size or board in the editor and every panel is recalculated.
| Panel | Size (mm) | Formula |
|---|---|---|
| Front cover | 133.3 × 188.5 | L + T/2 × H + T |
| Spine | 3.5 × 188.5 | spine × H + T |
| Back cover | 133.3 × 188.5 | L + T/2 × H + T |
| Inside right | 129.3 × 188.5 | L + T/2 − mouth × H + T |
| Top glue flap ×2 | 124.8 × 12 | – |
| Bottom glue flap ×2 | 124.8 × 12 | – |
| Inside left | 129.3 × 188.5 | L + T/2 − mouth × H + T |
Adjustable in the editor
Beyond the size and board, this structure exposes 5 options; the template and 3D preview follow each change.
- Layout2 options
- Spinemm
- Glue flapsmm
- Thumb cuton / off
- Thumb cut radiusmm
The record jacket family
The same structure with sizes, boards and options set for a use.
Preset
Preset
Preset
Preset
Preset
Preset
Preset
Similar structures
Other structures built in a similar way, matched on code family, category, closures and proportions.
Make this dvd gatefold wallet yours
Open it in the editor to set your size, drop artwork on each face, check bleed and safe areas, and export print-ready PDF with the dieline on its own layer — or stage it in a 3D scene for a mockup.
