The real blank at this size, folded by the same engine as the studio. The artwork is a sample from a fictional brand — swap in your own in the editor.
Parametric structureBags & pouches
Vacuum bag with bacon dieline
Clear vacuum-sealed bag drawn tight over sliced bacon, with a round hang hole in the top seal. A ready-sized preset of the sachet — change its size and the cut outline, bleed and safe area are redrawn to match.
Inside160 × 240 mm
Outside160 × 240 mm
Flat blank160 × 240 mm
Download the dielinePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, cut, crease and bleed on separate layers, without a watermark. See plans
- Reference
- —
- Inside size
- Width 160 · Height 240 mm
- Size range
- Width 25–250 · Height 30–320 mm
- Manufacturing
- 160 × 240 mm score to score · inside vs outside sizes
- Parts
- 2 parts — Front web, Back web
- Board area
- 0.077 m² · about 16 up on a 720 × 1020 mm sheet
- Default board
- Clear PET / PE laminate · 0.08 mm caliper
- Board options
- Met PET/PEWhite PET/PEClear PET/PEKraft/PE
- Good for
The flat dieline
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed. How to read a dieline.
