Preview image
The real blank at this size, folded by the same engine as the studio. The artwork is a sample from a fictional brand — swap in your own in the editor.
FEFCO 0441Trays & lids
Photo keepsake tray — Tray with hinged lid dieline
Editable 205 × 155 × 55 mm starting point using tray with hinged lid. Adjust the dimensions to your product before prototyping. A ready-sized preset of the tray with hinged lid — change the length, width and height and every panel, tuck and glue flap is redrawn to match.
Inside205 × 155 × 55 mm
Outside217.8 × 159.8 × 57.4 mm
Flat blank319.8 × 448.4 mm
Download the dielinePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, cut, crease and bleed on separate layers, without a watermark. See plans
- Reference
- FEFCO 0441
- Inside size
- Length 205 · Width 155 · Height 55 mm
- Size range
- Length 100–700 · Width 70–500 · Height 40–300 mm
- Manufacturing
- 209.8 × 156.6 × 56.6 mm score to score · inside vs outside sizes
- Parts
- One blank
- Board area
- 0.131 m² · about 4 up on a 720 × 1020 mm sheet
- Default board
- E-flute kraft / kraft · 1.6 mm caliper
- Board options
- E-flute KE-flute WB-fluteF-flute
- Good for
The flat dieline
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed. How to read a dieline.
- Crease
- Cut
- Glue area
- Bleed 3 mm
How the blank is sized
Score-to-score panel sizes of this FEFCO 0441 blank at the default size, with the formula each one follows. L, W and H are the inside dimensions; T is the board caliper (1.6 mm for E-flute kraft / kraft). Change the size or board in the editor and every panel is recalculated.
| Panel | Size (mm) | Formula |
|---|---|---|
| Base | 209.8 × 156.6 | L + 3T × W + T |
| Front | 209.8 × 55 | L + 3T × H |
| Back | 209.8 × 56.6 | L + 3T × H + T |
| Left end | 55 × 156.6 | W + T × H |
| Right end | 55 × 156.6 | W + T × H |
| Corner flap ×4 | 55 × 53.4 | H × H − T |
| Lid | 209.8 × 158.2 | L + 7T × W + 2T |
| Lid front skirt | 216.2 × 22 | – |
| Lid side skirt ×2 | 22 × 158.2 | – × W + 2T |
| Lid corner flap ×2 | 22 × 20.4 | – |
Adjustable in the editor
Beyond the size and board, this structure exposes 1 option; the template and 3D preview follow each change.
- Lid skirt depthmm
The tray with hinged lid family
The same structure with sizes, boards and options set for a use.
Preset
Preset
Preset
Preset
Preset
Preset
Preset
Preset
Preset
Preset
Preset
Similar structures
Other structures built in a similar way, matched on code family, category, closures and proportions.
Make this photo keepsake tray — tray with hinged lid yours
Open it in the editor to set your size, drop artwork on each face, check bleed and safe areas, and export print-ready PDF with the dieline on its own layer — or stage it in a 3D scene for a mockup.
