The real blank at this size, folded by the same engine as the studio. The artwork is a sample from a fictional brand — swap in your own in the editor.
FEFCO 0441Trays & lids
Shoe box with hinged lid 330×210×120 dieline
The lid stays on the box in the stockroom. A ready-sized preset of the tray with hinged lid — change the length, width and height and every panel, tuck and glue flap is redrawn to match.
Inside330 × 210 × 120 mm
Outside342.8 × 214.8 × 122.4 mm
Flat blank574.8 × 706.4 mm
Download the dielinePro
Sign in to download. Dieline downloads are part of Pro: PDF, Illustrator, SVG and DXF, cut, crease and bleed on separate layers, without a watermark. See plans
- Reference
- FEFCO 0441
- Inside size
- Length 330 · Width 210 · Height 120 mm
- Size range
- Length 100–700 · Width 70–500 · Height 40–300 mm
- Manufacturing
- 334.8 × 211.6 × 121.6 mm score to score · inside vs outside sizes
- Parts
- One blank
- Board area
- 0.356 m² · about 1 up on a 720 × 1020 mm sheet
- Default board
- E-flute kraft / kraft · 1.6 mm caliper
- Board options
- E-flute KE-flute WB-fluteF-flute
- Good for
The flat dieline
Exactly what the downloads contain, drawn from the template at its default size, with a 3 mm bleed. How to read a dieline.
- Crease
- Cut
- Glue area
- Bleed 3 mm
How the blank is sized
Score-to-score panel sizes of this FEFCO 0441 blank at the default size, with the formula each one follows. L, W and H are the inside dimensions; T is the board caliper (1.6 mm for E-flute kraft / kraft). Change the size or board in the editor and every panel is recalculated.
| Panel | Size (mm) | Formula |
|---|---|---|
| Base | 334.8 × 211.6 | L + 3T × W + T |
| Front | 334.8 × 120 | L + 3T × H |
| Back | 334.8 × 121.6 | L + 3T × H + T |
| Left end | 120 × 211.6 | W + T × H |
| Right end | 120 × 211.6 | W + T × H |
| Corner flap ×4 | 104.2 × 118.4 | – × H − T |
| Lid | 334.8 × 213.2 | L + 7T × W + 2T |
| Lid front skirt | 341.2 × 40 | – |
| Lid side skirt ×2 | 40 × 213.2 | – × W + 2T |
| Lid corner flap ×2 | 40 × 38.4 | – |
Adjustable in the editor
Beyond the size and board, this structure exposes 1 option; the template and 3D preview follow each change.
- Lid skirt depthmm
